A pulp molding production line is a complete automated system that turns recycled paper and plant fiber into finished molded products — egg trays, egg cartons, tableware, cup lids, and industrial packaging. A full line covers every stage: pulping, vacuum forming, transfer, drying, and stacking.
For nearly 30 years, Besure has built pulp molding production lines for manufacturers and exporters worldwide. As a China-Europe joint venture integrating European technology since 1997, we deliver lines engineered for stable high-volume output, low energy consumption, and long service life.
Below are the complete production lines we manufacture. Each is configured to your target product, capacity, and budget.
What a complete pulp molding production line includes
A complete Besure pulp molding production line is built from five core systems working together — the forming machine is the heart of the line, but it is only one part of the full setup:
- Pulping system — hydrapulper, pulp tank, water tank, pulp pump, water pump, agitator, consistency controller, and control cabinet. The choice of raw material affects final quality; see our guide to pulp molding raw materials.
- Forming system (main machine) — where the product is shaped. The internal process depends on the product and molding type: wet-press lines (tableware, cups & cup lids, fine-art packaging) run forming → hot pressing → trimming → stacking; dry-press lines (egg cartons, egg trays, industrial packaging, medical containers) run forming → drying, with hot pressing added only when a smoother finish is needed.
- Vacuum system — provides the vacuum the main machine needs when forming and transferring the product.
- Air compressor system — supplies compressed air for transferring the product during production.
- High-pressure water system — delivers high-pressure water to clean the main machine’s molds.
Drying and pressing design is one of the biggest factors in energy cost and product consistency; learn more in our guide to drying of pulp molding. Every line is delivered with factory layout design and on-site support.
Choosing the right production line
The best configuration depends on three things:
- Product type — egg cartons, egg trays, tableware, and industrial packaging each use different molds and forming setups.
- Target capacity — our lines range from entry-level to high-output configurations.
- Drying energy — natural gas, LPG, or diesel, chosen to match local energy costs.
Not sure which line fits your needs? Tell us your target product and volume, and our engineers will recommend a configuration and send a quotation.Get a Free Quote
Frequently asked questions
What is a pulp molding production line?
It is a complete automated system that converts recycled paper or plant fiber into molded products such as egg trays, egg cartons, and tableware, covering pulping through to drying and stacking.
How much does a pulp molding production line cost?
Price depends on product type, capacity, automation level, and drying system. Besure provides a tailored quotation — price on request.
What products can it make?
Common products include egg trays, egg cartons, molded fiber tableware, cup lids, industrial packaging, and medical containers. Beyond these, molded pulp applications keep expanding into new categories — if you have a new product or market in mind, we’d love to talk and develop it with you.
What raw materials are used?
Waste paper, recycled paper pulp, and plant fiber pulp.
